2024 T3 T4 Aluminium Sheet
2024 aluminium is with copper as the primary alloying element, and alloys were known as duralumin. It is used in applications requiring high strength to weight ratio, as well as good fatigue resistance. It is weldable only through friction welding, and has average machinability.
Share to
Product Parameters
| Product Name | 2024 T3 T4 Aluminium Sheet | |
| Size | Thickness | 0.5-10mm |
| Width | 800-2500mm | |
| Length | 900-10000mm | |
| Alloy | 2024 | |
| Temper | T3 / T4 / O/T6 | |
| Standard | ASTM-B209 EN480 GB/T3880 | |
| Surface | Smooth and Clean | |
| Product Performance | 1) The high intensity heat alloy2) Good mechanical properties3) Easy processing4) Corrosion resistance, resistance to oxidation | |
| Related Alloy | 2024A 2014 2014A 2017 2017A 2218 2219 aluminum sheet | |
| Related Temper | T3 /T4 /O/T6 | |
| MOQ | 3 Metric Tons | |
| Supply Ability | 6000 Metric Ton / Month | |
| Packaging | In wooden cases or based on customer requirements | |
Appication
It is mainly used in aviation , aircraft, airbus , regulating valve parts ,worn gear and key,bike frame, auto parts and so on.
Chemical Compostion
| Alloy | Chemical Composition (%) | ||||||||||
| 2024 | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | each | total | Balance |
| 0.5 | 0.5 | 3.8-4.9 | 0.3-0.9 | 1.2-1.8 | 0.1 | 0.25 | 0.15 | 0.05 | 0.15 | AI | |
Quality Control
Our company has built the quality supervision department and aluminum lab to control the quality . We have complete test line to make sure our products’s quality to meet per customers requirements
